Kawasaki NINJA 650, Z650 & Z650RS Page




Scroll below bike photo for details and dyno tests









Ivan's® ECU flash for: 2023-2025 Kawasaki NINJA 650, Z650, & Z650RS models - Available now !!

Ivan's® ECU flash for:
2023-2025 Ninja 650
- $350.00 + Return shipping

Ivan's® ECU flash for: 2023-2025 Z650 - $350.00 + Return shipping
Ivan's® ECU flash for:
2023-2025 Z650RS
- $350.00 + Return shipping

We can reprogram for USA, Canada, & Europe !!

Ivan's Performance ECU flash is for CLOSED COURSE COMPETITION USE ONLY !!


*****
REQUIRES 89 OCTANE OR HIGHER FUEL
*****

My ECU tuning philosophy and more ECU info can be found on this page:
ECU PAGE

When sending your ECU, please print and fill out - This ECU Programming info form
I will contact you for your payment after I receive your ECU.

Your ECU is located under the fuel tank, on top of the airbox


More than 6 months of research and development has been invested into my
Kawasaki NINJA 650, Z650, & Z650RS models !!

This includes reverse engineering all the stock North American
Kawasaki NINJA 650, Z650, & Z650RS model ECUs for this bike
,
dyno test and tune
, and on the road testing.

My exclusive software & tuning experience offers you the best result possible.
(because my software can access the entire file, and commercially available software does not)

This offers you the most refined feeling, smoothest, most powerful, best driveability, best fuel economy

than you will find in any other ECU flash offering for your
Kawasaki NINJA 650, Z650, & Z650RS models.


___________________________________________________________________________________________________



My Kawasaki NINJA 650, Z650, & Z650RS ECU programming (Re-Flash) includes the following:



1) Fix all fueling problems inside the ECU.

(The ones that cannot be fixed with an external fuel tuner or other commercially available methods)
a) All gear dependent maps equalized
b) Main fuel tables (A/n) - adjusted specifically for your exhaust at all active throttle positions.
c) Vacuum tables (MAP)- adjusted specifically for your exhaust in all active areas.
d) Emissions compliant sub-routines that affect driveability - turned off.

e) All response delay filters (detuning items) - turned off.
f) Deceleration tables thoroughly tested and re-adjusted for best closed to part throttle response.
g) O2 sensor disabled - No need to unplug, or can be removed if desired.

Includes fueling changes !!
External fuel tuner not needed - just plug in and go !!



2) Disable fuel cut - ie; Jerky throttle

Don't know what "fuel cut" is? - CLICK HERE

a) Engine stays running when the throttle is closed.
(with stock ECU programming, the injectors are not running when you decel)


b) Gets rid of poor, imprecise throttle transitions from closed throttle.

c) Eliminates feeling of driveline lash and jerky, delayed throttle response.

d) Changing gears is dramatically improved.
Without fuel cut disabled, "neutral throttle" is not possible.
This is the direct cause of your touchy, jerky throttle
because the engine isn't running during decel.

e) Dramatic improvement upon re-application from closed throttle (in all riding conditions).
(Throttle re-application response feels like our old carbureted bikes used to feel)

f) No need for a different throttle tube ratio to try to prevent jerky response.
(which it cannot do anyway)

g) Gets rid of annoying popping and banging during decel and when re-applying the throttle from closed.


3) Close AIS valve electronically


No need for block-off plates for air injection system
No popping on decel !!
No hoses to plug - Just plug in your ECU and go !!


4) Cooling Fan comes on at 195 degrees and goes off at 186

Helps keep engine cooler when you are stuck in traffic.

5) Reprogram Sub-throttles for best response and to remove power restrictions


a) Allows all of the 650 engine's available power - whenever you ask for it.
    All power restrictions are removed.

b) Gives immediate engine response to the throttle with no restrictions.


c) Low rpm power is improved, while preserving fuel economy.

d) Response delay filters turned off - part of original detuning.

e)
Engine responds and feels immediate, light and rev-happy


7) Complete custom re-curve of ignition timing


a) Set main timing tables for maximium power and driveability across the entire rpm range and all throttle positions.
This also helps provide better fuel economy, and less vibration when cruising and moderate acceleration.

b) All gear dependent maps equalized and adjusted for best power and fuel econom
y.
Adjust timing to be the same for all gears.

c) All emissions compliant /detuning sub-routines turned off.


d) Gets rid of part throttle timing retarder for more response and less vibration when cruising and moderate acceleration.

e) Gets rid of ignition timing issues that are unique to the
NINJA 650, Z650, & Z650RS models.


8)
Reduced running temperatures

9) All driveability inhibitors removed.

10) Free updates when/if we make improvements.
(shipping not included)

11) Free updates if you change your exhaust.

(shipping not included)

12) Return your ecu back to stock at no charge for any reason.
(shipping not included)

14) Anything that compromises performance and/or driveability is eliminated.

Includes fueling changes !!
External fuel tuner not needed - just plug in and go !!



All testing and tuning was done in house on the Ninja 650 shown above !!


Dyno tuning not necessary !!


We can reprogram for USA, Canada, Europe!!


European customers for this model must contact our European partner here:
http://www.ecu-flashing.com/contact-us/


ECU reprogramming may not comply with federal safety/emission laws !!
ECU reprogramming may not comply with your warranty !!

Ivan's Performance ECU flash is for CLOSED COURSE COMPETITION USE ONLY !!


_________________________________________________________________________________________________




Dyno tests

ALL TESTS ARE SHOWN IN 5th GEAR



All stock vs. Ivan's ECU programming

My ECU flash on an all stock Ninja 650, Z650, & Z650RS is a very significant gain in power and driveability.








All stock vs. final result - 9 hp is a very large gain for a 650 !!

Kawasaki really neutered this bike in many areas
.
